7 Coding PL/SQL Procedures and Packages

Naming Procedures and Functions

Because a procedure or function is stored in the database, it must be named. This distinguishes it from other stored procedures and makes it possible for applications to call it. Each publicly-visible procedure or function in a schema must have a unique name, and the name must be a legal PL/SQL identifier.

Parameters for Procedures and Functions

Stored procedures and functions can take parameters. The following example shows a stored procedure that is similar to the anonymous block in "Anonymous Blocks".

PROCEDURE Get_emp_names (Dept_num IN NUMBER) IS
   Emp_name       VARCHAR2(10);
   CURSOR         c1 (Depno NUMBER) IS
                     SELECT Ename FROM Emp_tab
                        WHERE deptno = Depno;
BEGIN
   OPEN c1(Dept_num);
   LOOP
      FETCH c1 INTO Emp_name;
      EXIT WHEN C1%NOTFOUND;
      DBMS_OUTPUT.PUT_LINE(Emp_name);
   END LOOP;
   CLOSE c1;
END;

In this stored procedure example, the department number is an input parameter which is used when the parameterized cursor c1 is opened.

The formal parameters of a procedure have three major attributes, described in Table 7-1.

PROCEDURE Get_emp_names(Dept_num IN Emp_tab.Deptno%TYPE)

Dept_number    number(2);
...
PROCEDURE Get_emp_names(Dept_num IN Dept_number%TYPE);

PROCEDURE Get_emp_rec (Emp_number  IN  Emp_tab.Empno%TYPE,
                       Emp_ret     OUT Emp_tab%ROWTYPE) IS
BEGIN
   SELECT Empno, Ename, Job, Mgr, Hiredate, Sal, Comm, Deptno
      INTO Emp_ret
      FROM Emp_tab
      WHERE Empno = Emp_number;
END;

DECLARE
   Emp_row      Emp_tab%ROWTYPE;     -- declare a record matching a
                                     -- row in the Emp_tab table
BEGIN
   Get_emp_rec(7499, Emp_row);   -- call for Emp_tab# 7499
   DBMS_OUTPUT.PUT(Emp_row.Ename || ' '                || Emp_row.Empno);
   DBMS_OUTPUT.PUT(' '           || Emp_row.Job || ' ' || Emp_row.Mgr);
   DBMS_OUTPUT.PUT(' '           || Emp_row.Hiredate   || ' ' || Emp_row.Sal);
   DBMS_OUTPUT.PUT(' '           || Emp_row.Comm || ' '|| Emp_row.Deptno);
   DBMS_OUTPUT.NEW_LINE;
END;

FUNCTION Get_emp_rec (Dept_num IN Emp_tab.Deptno%TYPE)
   RETURN Emp_tab%ROWTYPE IS ...

PROCEDURE Get_emp_names (Dept_num IN NUMBER DEFAULT 20) IS ...

PROCEDURE Get_emp_names (Dept_num IN NUMBER := 20) IS ...

Creating Stored Procedures and Functions

Use a text editor to write the procedure or function. At the beginning of the procedure, place the following statement:

CREATE PROCEDURE Procedure_name AS   ...

For example, to use the example in "%TYPE and %ROWTYPE Attributes ", create a text (source) file called get_emp.sql containing the following code:

CREATE PROCEDURE Get_emp_rec (Emp_number  IN  Emp_tab.Empno%TYPE,
                              Emp_ret     OUT Emp_tab%ROWTYPE) AS
BEGIN
   SELECT Empno, Ename, Job, Mgr, Hiredate, Sal, Comm, Deptno
      INTO Emp_ret
      FROM Emp_tab
      WHERE Empno = Emp_number;
END;
/

Then, using an interactive tool such as SQL*Plus, load the text file containing the procedure by entering the following statement:

SQL> @get_emp

This loads the procedure into the current schema from the get_emp.sql file (.sql is the default file extension). Note the slash (/) at the end of the code. This is not part of the code; it just activates the loading of the procedure.

Use the CREATE [OR REPLACE] FUNCTION... statement to store functions.

You can use either the keyword IS or AS after the procedure parameter list.

Altering Stored Procedures and Functions

To alter a stored procedure or function, you must first drop it using the DROP PROCEDURE or DROP FUNCTION statement, then re-create it using the CREATE PROCEDURE or CREATE FUNCTION statement. Alternatively, use the CREATE OR REPLACE PROCEDURE or CREATE OR REPLACE FUNCTION statement, which first drops the procedure or function if it exists, then re-creates it as specified.

Dropping Procedures and Functions

A standalone procedure, a standalone function, a package body, or an entire package can be dropped using the SQL statements DROP PROCEDURE, DROP FUNCTION, DROP PACKAGE BODY, and DROP PACKAGE, respectively. A DROP PACKAGE statement drops both the specification and body of a package.

The following statement drops the Old_sal_raise procedure in your schema:

DROP PROCEDURE Old_sal_raise;

External Procedures

A PL/SQL procedure executing on an Oracle Database instance can call an external procedure written in a 3GL. The 3GL procedure runs in a separate address space from that of the database.

PL/SQL Packages

A package is an encapsulated collection of related program objects (for example, procedures, functions, variables, constants, cursors, and exceptions) stored together in the database.

Using packages is an alternative to creating procedures and functions as standalone schema objects. Packages have many advantages over standalone procedures and functions. For example, they:

• Let you organize your application development more efficiently.

• Let you grant privileges more efficiently.

• Let you modify package objects without recompiling dependent schema objects.

• Enable Oracle Database to read multiple package objects into memory at once.

• Can contain global variables and cursors that are available to all procedures and functions in the package.

• Let you overload procedures or functions. Overloading a procedure means creating multiple procedures with the same name in the same package, each taking arguments of different number or datatype.




  See Also: Oracle Database PL/SQL User's Guide and Reference for more information about subprogram name overloading




The specification part of a package declares the public types, variables, constants, and subprograms that are visible outside the immediate scope of the package. The body of a package defines the objects declared in the specification, as well as private objects that are not visible to applications outside the package.

CREATE PACKAGE BODY Employee_management AS
   FUNCTION Hire_emp (Name VARCHAR2, Job VARCHAR2,
      Mgr NUMBER, Hiredate DATE, Sal NUMBER, Comm NUMBER,
      Deptno NUMBER) RETURN NUMBER IS
       New_empno    NUMBER(10);

-- This function accepts all arguments for the fields in
-- the employee table except for the employee number.
-- A value for this field is supplied by a sequence.
-- The function returns the sequence number generated
-- by the call to this function.

   BEGIN
      SELECT Emp_sequence.NEXTVAL INTO New_empno FROM dual;
      INSERT INTO Emp_tab VALUES (New_empno, Name, Job, Mgr,
         Hiredate, Sal, Comm, Deptno);
      RETURN (New_empno);
   END Hire_emp;

   PROCEDURE fire_emp(emp_id IN NUMBER) AS

-- This procedure deletes the employee with an employee
-- number that corresponds to the argument Emp_id. If
-- no employee is found, then an exception is raised.

   BEGIN
      DELETE FROM Emp_tab WHERE Empno = Emp_id;
      IF SQL%NOTFOUND THEN
      Raise_application_error(-20011, 'Invalid Employee
         Number: ' || TO_CHAR(Emp_id));
   END IF;
END fire_emp;

PROCEDURE Sal_raise (Emp_id IN NUMBER, Sal_incr IN NUMBER) AS

-- This procedure accepts two arguments. Emp_id is a
-- number that corresponds to an employee number.
-- SAL_INCR is the amount by which to increase the
-- employee's salary. If employee exists, then update
-- salary with increase.

   BEGIN
      UPDATE Emp_tab
         SET Sal = Sal + Sal_incr
         WHERE Empno = Emp_id;
      IF SQL%NOTFOUND THEN
         Raise_application_error(-20011, 'Invalid Employee
            Number: ' || TO_CHAR(Emp_id));
      END IF;
   END Sal_raise;
END Employee_management;

SQL> CREATE SEQUENCE Emp_sequence
   > START WITH 8000 INCREMENT BY 10;

PL/SQL Object Size Limitation

The size limitation for PL/SQL stored database objects such as procedures, functions, triggers, and packages is the size of the DIANA (Descriptive Intermediate Attributed Notation for Ada) code in the shared pool in bytes. The UNIX limit on the size of the flattened DIANA/pcode size is 64K but the limit may be 32K on desktop platforms such as DOS and Windows.

The most closely related number that a user can access is the PARSED_SIZE in the data dictionary view USER_OBJECT_SIZE. That gives the size of the DIANA in bytes as stored in the SYS.IDL_xxx$ tables. This is not the size in the shared pool. The size of the DIANA part of PL/SQL code (used during compilation) is significantly larger in the shared pool than it is in the system table.

Creating Packages

Each part of a package is created with a different statement. Create the package specification using the CREATE PACKAGE statement. The CREATE PACKAGE statement declares public package objects.

To create a package body, use the CREATE PACKAGE BODY statement. The CREATE PACKAGE BODY statement defines the procedural code of the public procedures and functions declared in the package specification.

You can also define private, or local, package procedures, functions, and variables in a package body. These objects can only be accessed by other procedures and functions in the body of the same package. They are not visible to external users, regardless of the privileges they hold.

It is often more convenient to add the OR REPLACE clause in the CREATE PACKAGE or CREATE PACKAGE BODY statements when you are first developing your application. The effect of this option is to drop the package or the package body without warning. The CREATE statements would then be the following:

CREATE OR REPLACE PACKAGE Package_name AS ...

and

CREATE OR REPLACE PACKAGE BODY Package_name AS ...

Naming Packages and Package Objects

The names of a package and all public objects in the package must be unique within a given schema. The package specification and its body must have the same name. All package constructs must have unique names within the scope of the package, unless overloading of procedure names is desired.

Package Invalidations and Session State

Each session that references a package object has its own instance of the corresponding package, including persistent state for any public and private variables, cursors, and constants. If any of the session's instantiated packages (specification or body) are invalidated, then all package instances in the session are invalidated and recompiled. As a result, the session state is lost for all package instances in the session.

When a package in a given session is invalidated, the session receives the following error the first time it attempts to use any object of the invalid package instance:

ORA-04068: existing state of packages has been discarded

The second time a session makes such a package call, the package is reinstantiated for the session without error.

In most production environments, DDL operations that can cause invalidations are usually performed during inactive working hours; therefore, this situation might not be a problem for end-user applications. However, if package invalidations are common in your system during working hours, then you might want to code your applications to handle this error when package calls are made.

Packages Supplied With Oracle Database

There are many packages provided with Oracle Database, either to extend the functionality of the database or to give PL/SQL access to SQL features. You can call these packages from your application.

Overview of Bulk Binds

Oracle Database uses two engines to run PL/SQL blocks and subprograms. The PL/SQL engine runs procedural statements, while the SQL engine runs SQL statements. During execution, every SQL statement causes a context switch between the two engines, resulting in performance overhead.

Performance can be improved substantially by minimizing the number of context switches required to run a particular block or subprogram. When a SQL statement runs inside a loop that uses collection elements as bind variables, the large number of context switches required by the block can cause poor performance. Collections include the following:

• Varrays

• Nested tables

• Index-by tables

• Host arrays

Binding is the assignment of values to PL/SQL variables in SQL statements. Bulk binding is binding an entire collection at once. Bulk binds pass the entire collection back and forth between the two engines in a single operation.

Typically, using bulk binds improves performance for SQL statements that affect four or more database rows. The more rows affected by a SQL statement, the greater the performance gain from bulk binds.

When to Use Bulk Binds

If you have scenarios like these in your applications, consider using bulk binds to improve performance.

DECLARE
   TYPE Numlist IS VARRAY (100) OF NUMBER;
   Id NUMLIST := NUMLIST(7902, 7698, 7839);
BEGIN

-- Efficient method, using a bulk bind
   FORALL i IN Id.FIRST..Id.LAST   -- bulk-bind the VARRAY
      UPDATE Emp_tab SET Sal = 1.1 * Sal
      WHERE Mgr = Id(i);

-- Slower method, running the UPDATE statements within a regular loop
   FOR i IN Id.FIRST..Id.LAST LOOP
      UPDATE Emp_tab SET Sal = 1.1 * Sal
      WHERE Mgr = Id(i);
   END LOOP;
END;

FORALL i in Emp_Data.FIRST..Emp_Data.LAST
    INSERT INTO Emp_tab VALUES(Emp_Data(i));

-- Find all employees whose manager's ID number is 7698.
DECLARE
   TYPE Var_tab IS TABLE OF VARCHAR2(20) INDEX BY BINARY_INTEGER;
   Empno VAR_TAB;
   Ename VAR_TAB;
   Counter NUMBER;
   CURSOR C IS
      SELECT Empno, Ename FROM Emp_tab WHERE Mgr = 7698;
BEGIN

-- Efficient method, using a bulk bind
    SELECT Empno, Ename BULK COLLECT INTO Empno, Ename
        FROM Emp_Tab WHERE Mgr = 7698;

-- Slower method, assigning each collection element within a loop.

   counter := 1;
   FOR rec IN C LOOP
      Empno(Counter) := rec.Empno;
      Ename(Counter) := rec.Ename;
      Counter := Counter + 1;
   END LOOP;
END;

DECLARE
   TYPE Emplist IS VARRAY(100) OF NUMBER;
   Empids EMPLIST := EMPLIST(7369, 7499, 7521, 7566, 7654, 7698);
   TYPE Bonlist IS TABLE OF Emp_tab.sal%TYPE;
   Bonlist_inst BONLIST;
BEGIN
   Bonlist_inst := BONLIST(1,2,3,4,5);

   FORALL i IN Empids.FIRST..empIDs.LAST
      UPDATE Emp_tab SET Bonus = 0.1 * Sal
      WHERE Empno = Empids(i)
      RETURNING Sal BULK COLLECT INTO Bonlist;

   FOR i IN Empids.FIRST..Empids.LAST LOOP
      UPDATE Emp_tab Set Bonus = 0.1 * sal
         WHERE Empno = Empids(i)
       RETURNING Sal INTO BONLIST(i);
   END LOOP;
END;

Triggers

A trigger is a special kind of PL/SQL anonymous block. You can define triggers to fire before or after SQL statements, either on a statement level or for each row that is affected. You can also define INSTEAD OF triggers or system triggers (triggers on DATABASE and SCHEMA).

Disadvantages of the Timestamp Model

The disadvantage of this dependency model is that it is unnecessarily restrictive. Recompilation of dependent objects across the network are often performed when not strictly necessary, leading to performance degradation.

Furthermore, on the client side, the timestamp model can lead to situations that block an application from running at all, if the client-side application is built using PL/SQL version 2. Earlier releases of tools, such as Oracle Forms, that used PL/SQL version 1 on the client side did not use this dependency model, because PL/SQL version 1 had no support for stored procedures.

For releases of Oracle Forms that are integrated with PL/SQL version 2 on the client side, the timestamp model can present problems. For example, during the installation of the application, the application is rendered invalid unless the client-side PL/SQL procedures that it uses are recompiled at the client site. Also, if a client-side procedure depends on a server procedure, and if the server procedure is changed or automatically recompiled, then the client-side PL/SQL procedure must then be recompiled. Yet in many application environments (such as Forms runtime applications), there is no PL/SQL compiler available on the client. This blocks the application from running at all. The client application developer must then redistribute new versions of the application to all customers.

When Does a Signature Change?

Here is information on when a signature changes.

Switching Datatype Classes

A signature changes when you switch from one class of datatype to another. Within each datatype class, there can be several types. Changing a parameter datatype from one type to another within a class does not cause the signature to change. Datatypes that are not listed in the following table, such as NCHAR or TIMESTAMP, are not part of any class; changing their type always causes a signature mismatch.

VARCHAR types: VARCHAR2, VARCHAR, STRING, LONG, ROWID

Character types: CHARACTER, CHAR

Raw types: RAW, LONG RAW

Integer types: BINARY_INTEGER, PLS_INTEGER, BOOLEAN, NATURAL, POSITIVE, POSITIVEN, NATURALN

Number types: NUMBER, INTEGER, INT, SMALLINT, DECIMAL, DEC, REAL, FLOAT, NUMERIC, DOUBLE PRECISION, DOUBLE PRECISION, NUMERIC

Date types: DATE, TIMESTAMP, TIMESTAMP WITH TIME ZONE, TIMESTAMP WITH LOCAL TIME ZONE, INTERVAL YEAR TO MONTH, INTERVAL DAY TO SECOND

PROCEDURE P1 (Param1 NUMBER);
PROCEDURE P1 (Param1 IN NUMBER);

PROCEDURE P1 (Param1 IN NUMBER := 100);
PROCEDURE P1 (Param1 IN NUMBER := 200);

Examples of Changing Procedure Signatures

Using the Get_emp_names procedure defined in "Parameters for Procedures and Functions", if the procedure body is changed to the following:

DECLARE
   Emp_number  NUMBER;
   Hire_date   DATE;
BEGIN
-- date format model changes

   SELECT Ename, To_char(Hiredate, 'DD/MON/YYYY')
      INTO Emp_name, Hire_date
      FROM Emp_tab
      WHERE Empno = Emp_number;
END;

The specification of the procedure has not changed, so its signature has not changed.

But if the procedure specification is changed to the following:

CREATE OR REPLACE PROCEDURE Get_emp_name (
   Emp_number  IN  NUMBER,
   Hire_date   OUT DATE,
   Emp_name    OUT VARCHAR2) AS

And if the body is changed accordingly, then the signature changes, because the parameter Hire_date has a different datatype.

However, if the name of that parameter changes to When_hired, and the datatype remains VARCHAR2, and the mode remains OUT, the signature does not change. Changing the name of a formal parameter does not change the signature of the unit.

Consider the following example:

CREATE OR REPLACE PACKAGE Emp_package AS
    TYPE Emp_data_type IS RECORD (
        Emp_number NUMBER,
        Hire_date  VARCHAR2(12),
        Emp_name   VARCHAR2(10));
    PROCEDURE Get_emp_data
        (Emp_data IN OUT Emp_data_type);
END;

CREATE OR REPLACE PACKAGE BODY Emp_package AS
    PROCEDURE Get_emp_data
        (Emp_data IN OUT Emp_data_type) IS
   BEGIN
       SELECT Empno, Ename, TO_CHAR(Hiredate, 'DD/MON/YY')
           INTO Emp_data
           FROM Emp_tab
           WHERE Empno = Emp_data.Emp_number;
   END;
END;

If the package specification is changed so that the record's field names are changed, but the types remain the same, then this does not affect the signature. For example, the following package specification has the same signature as the previous package specification example:

CREATE OR REPLACE PACKAGE Emp_package AS
    TYPE Emp_data_type IS RECORD (
        Emp_num    NUMBER,         -- was Emp_number
        Hire_dat   VARCHAR2(12),   -- was Hire_date
        Empname    VARCHAR2(10));  -- was Emp_name
    PROCEDURE Get_emp_data
        (Emp_data IN OUT Emp_data_type);
END;

Changing the name of the type of a parameter does not cause a change in the signature if the type remains the same as before. For example, the following package specification for Emp_package is the same as the first one:

CREATE OR REPLACE PACKAGE Emp_package AS
    TYPE Emp_data_record_type IS RECORD (
        Emp_number NUMBER,
        Hire_date  VARCHAR2(12),
        Emp_name   VARCHAR2(10));
    PROCEDURE Get_emp_data
        (Emp_data IN OUT Emp_data_record_type);
END;

Dependency Resolution

When REMOTE_DEPENDENCIES_MODE = TIMESTAMP (the default value), dependencies among program units are handled by comparing timestamps at runtime. If the timestamp of a called remote procedure does not match the timestamp of the called procedure, then the calling (dependent) unit is invalidated and must be recompiled. In this case, if there is no local PL/SQL compiler, then the calling application cannot proceed.

In the timestamp dependency mode, signatures are not compared. If there is a local PL/SQL compiler, then recompilation happens automatically when the calling procedure is run.

When REMOTE_DEPENDENCIES_MODE = SIGNATURE, the recorded timestamp in the calling unit is first compared to the current timestamp in the called remote unit. If they match, then the call proceeds. If the timestamps do not match, then the signature of the called remote subprogram, as recorded in the calling subprogram, is compared with the current signature of the called subprogram. If they do not match (using the criteria described in the section "When Does a Signature Change?"), then an error is returned to the calling session.

Suggestions for Managing Dependencies

Follow these guidelines for setting the REMOTE_DEPENDENCIES_MODE parameter:

• Server-side PL/SQL users can set the parameter to TIMESTAMP (or let it default to that) to get the timestamp dependency mode.

• Server-side PL/SQL users can choose to use the signature dependency mode if they have a distributed system and they want to avoid possible unnecessary recompilations.

• Client-side PL/SQL users should set the parameter to SIGNATURE. This allows:

  • Installation of new applications at client sites, without the need to recompile procedures.

  • Ability to upgrade the server, without encountering timestamp mismatches.

• When using signature mode on the server side, add new procedures to the end of the procedure (or function) declarations in a package specification. Adding a new procedure in the middle of the list of declarations can cause unnecessary invalidation and recompilation of dependent procedures.

Fetching Data

The following package defines a PL/SQL cursor variable type Emp_val_cv_type, and two procedures. The first procedure, Open_emp_cv, opens the cursor variable using a bind variable in the WHERE clause. The second procedure, Fetch_emp_data, fetches rows from the Emp_tab table using the cursor variable.

CREATE OR REPLACE PACKAGE Emp_data AS
  TYPE Emp_val_cv_type IS REF CURSOR RETURN Emp_tab%ROWTYPE;
  PROCEDURE Open_emp_cv (Emp_cv          IN OUT Emp_val_cv_type,
                         Dept_number     IN     INTEGER);
  PROCEDURE Fetch_emp_data (emp_cv       IN     Emp_val_cv_type,
                            emp_row      OUT    Emp_tab%ROWTYPE);
END Emp_data;

CREATE OR REPLACE PACKAGE BODY Emp_data AS
  PROCEDURE Open_emp_cv (Emp_cv      IN OUT Emp_val_cv_type,
                         Dept_number IN     INTEGER) IS
  BEGIN
    OPEN emp_cv FOR SELECT * FROM Emp_tab WHERE deptno = dept_number;
  END open_emp_cv;
  PROCEDURE Fetch_emp_data (Emp_cv      IN  Emp_val_cv_type,
                            Emp_row     OUT Emp_tab%ROWTYPE) IS
  BEGIN
    FETCH Emp_cv INTO Emp_row;
  END Fetch_emp_data;
END Emp_data;

The following example shows how to call the Emp_data package procedures from a PL/SQL block:

DECLARE
-- declare a cursor variable
   Emp_curs Emp_data.Emp_val_cv_type;
   Dept_number Dept_tab.Deptno%TYPE;
   Emp_row Emp_tab%ROWTYPE;

BEGIN
   Dept_number := 20;
-- open the cursor using a variable
   Emp_data.Open_emp_cv(Emp_curs, Dept_number);
-- fetch the data and display it
   LOOP
     Emp_data.Fetch_emp_data(Emp_curs, Emp_row);
     EXIT WHEN Emp_curs%NOTFOUND;
     DBMS_OUTPUT.PUT(Emp_row.Ename || '  ');
     DBMS_OUTPUT.PUT_LINE(Emp_row.Sal);
   END LOOP;
END;

Implementing Variant Records

The power of cursor variables comes from their ability to point to different cursors. In the following package example, a discriminant is used to open a cursor variable to point to one of two different cursors:

CREATE OR REPLACE PACKAGE Emp_dept_data AS
  TYPE Cv_type IS REF CURSOR;
  PROCEDURE Open_cv (Cv          IN OUT cv_type,
                     Discrim     IN     POSITIVE);
END Emp_dept_data;

CREATE OR REPLACE PACKAGE BODY Emp_dept_data AS
  PROCEDURE Open_cv (Cv      IN OUT cv_type,
                     Discrim IN     POSITIVE) IS
  BEGIN
    IF Discrim = 1 THEN
      OPEN Cv FOR SELECT * FROM Emp_tab WHERE Sal > 2000;
    ELSIF Discrim = 2 THEN
      OPEN Cv FOR SELECT * FROM Dept_tab;
    END IF;
  END Open_cv;
END Emp_dept_data;

You can call the Open_cv procedure to open the cursor variable and point it to either a query on the Emp_tab table or the Dept_tab table. The following PL/SQL block shows how to fetch using the cursor variable, and then use the ROWTYPE_MISMATCH predefined exception to handle either fetch:

DECLARE
  Emp_rec  Emp_tab%ROWTYPE;
  Dept_rec Dept_tab%ROWTYPE;
  Cv       Emp_dept_data.CV_TYPE;

BEGIN
  Emp_dept_data.open_cv(Cv, 1); -- Open Cv For Emp_tab Fetch
  Fetch cv INTO Dept_rec;       -- but fetch into Dept_tab record
                                -- which raises ROWTYPE_MISMATCH
  DBMS_OUTPUT.PUT(Dept_rec.Deptno);
  DBMS_OUTPUT.PUT_LINE('  ' || Dept_rec.Loc);

EXCEPTION
  WHEN ROWTYPE_MISMATCH THEN
    BEGIN
      DBMS_OUTPUT.PUT_LINE
           ('Row type mismatch, fetching Emp_tab data...');
      FETCH Cv INTO Emp_rec;
      DBMS_OUTPUT.PUT(Emp_rec.Deptno);
      DBMS_OUTPUT.PUT_LINE('  ' || Emp_rec.Ename);
    END;

Name Precedence

In SQL statements, the names of database columns take precedence over the names of functions with no parameters. For example, if schema Scott creates the following two objects:

CREATE TABLE Emp_tab(New_sal NUMBER ...);
CREATE FUNCTION New_sal RETURN NUMBER IS ...;

Then, in the following two statements, the reference to New_sal refers to the column Emp_tab.New_sal:

SELECT New_sal FROM Emp_tab;
SELECT Emp_tab.New_sal FROM Emp_tab;

To access the function new_sal, enter the following:

SELECT Scott.New_sal FROM Emp_tab;

CREATE TABLE Tax_table (
   Ss_no  NUMBER,
   Sal    NUMBER);

CREATE OR REPLACE FUNCTION tax_rate (ssn IN NUMBER, salary IN NUMBER) RETURN NUMBER IS
   sal_out NUMBER;
   BEGIN
      sal_out := salary * 1.1;
   END;

DECLARE
   Tax_id     NUMBER;
   Income_tax NUMBER;
BEGIN
   SELECT scott.tax_rate (Ss_no, Sal)
      INTO Income_tax
      FROM Tax_table
      WHERE Ss_no = Tax_id;
END;

Circle_area(Radius)
Payroll.Tax_rate(Empno)
scott.Payroll.Tax_rate@boston_server(Dependents, Empno)

Arguments

To pass any number of arguments to a function, supply the arguments within the parentheses. You must use positional notation; named notation is not supported. For functions that do not accept arguments, use ().

Using Default Values

The stored function Gross_pay initializes two of its formal parameters to default values using the DEFAULT clause. For example:

CREATE OR REPLACE FUNCTION Gross_pay
    (Emp_id  IN NUMBER,
     St_hrs  IN NUMBER DEFAULT 40,
     Ot_hrs  IN NUMBER DEFAULT 0) RETURN NUMBER AS
  ...

When calling Gross_pay from a procedural statement, you can always accept the default value of St_hrs. This is because you can use named notation, which lets you skip parameters. For example:

IF Gross_pay(Eenum, Ot_hrs => Otime) > Pay_limit
THEN ...

However, when calling Gross_pay from a SQL expression, you cannot accept the default value of St_hrs, unless you accept the default value of Ot_hrs. This is because you cannot use named notation.

Privileges

To call a PL/SQL function from SQL, you must either own or have EXECUTE privileges on the function. To select from a view defined with a PL/SQL function, you must have SELECT privileges on the view. No separate EXECUTE privileges are necessary to select from the view.

Restrictions

When a SQL statement is run, checks are made to see if it is logically embedded within the execution of an already running SQL statement. This occurs if the statement is run from a trigger or from a subprogram that was in turn called from the already running SQL statement. In these cases, further checks occur to determine if the new SQL statement is safe in the specific context.

The following restrictions are enforced on subprograms:

• A subprogram called from a query or DML statement may not end the current transaction, create or rollback to a savepoint, or ALTER the system or session.

• A subprogram called from a query (SELECT) statement or from a parallelized DML statement may not execute a DML statement or otherwise modify the database.

• A subprogram called from a DML statement may not read or modify the particular table being modified by that DML statement.

These restrictions apply regardless of what mechanism is used to run the SQL statement inside the subprogram or trigger. For example:

• They apply to a SQL statement called from PL/SQL, whether embedded directly in a subprogram or trigger body, run using the native dynamic mechanism (EXECUTE IMMEDIATE), or run using the DBMS_SQL package.

• They apply to statements embedded in Java with SQLJ syntax or run using JDBC.

• They apply to statements run with OCI using the callback context from within an "external" C function.

You can avoid these restrictions if the execution of the new SQL statement is not logically embedded in the context of the already running statement. PL/SQL's autonomous transactions provide one escape (see "Autonomous Transactions" ). Another escape is available using Oracle Call Interface (OCI) from an external C function, if you create a new connection rather than using the handle available from the OCIExtProcContext argument.

Declaring a Function

You can use the keywords DETERMINISTIC and PARALLEL_ENABLE in the syntax for declaring a function. These are optimization hints that inform the query optimizer and other software components about the following:

• Functions that need not be called redundantly

• Functions permitted within a parallelized query or parallelized DML statement

Only functions that are DETERMINISTIC are allowed in function-based indexes and in certain snapshots and materialized views.

A deterministic function depends solely on the values passed into it as arguments and does not reference or modify the contents of package variables or the database or have other side-effects. Such a function produces the same result value for any combination of argument values passed into it.

You place the DETERMINISTIC keyword after the return value type in a declaration of the function. For example:

CREATE FUNCTION F1 (P1 NUMBER) RETURN NUMBER DETERMINISTIC IS
BEGIN
  RETURN P1 * 2;
END;

You may place this keyword in the following places:

• On a function defined in a CREATE FUNCTION statement

• In a function declaration in a CREATE PACKAGE statement

• On a method declaration in a CREATE TYPE statement

You should not repeat the keyword on the function or method body in a CREATE PACKAGE BODY or CREATE TYPE BODY statement.

Certain performance optimizations occur on calls to functions that are marked DETERMINISTIC without any other action being required. The following features require that any function used with them be declared DETERMINISTIC:

• Any function used in a function-based index.

• Any function used in a materialized view, if that view is to qualify for Fast Refresh or is marked ENABLE QUERY REWRITE.

The preceding functions features attempt to use previously calculated results rather than calling the function when it is possible to do so.

Functions that fall in the following categories should typically be DETERMINISTIC:

• Functions used in a WHERE, ORDER BY, or GROUP BY clause

• Functions that MAP or ORDER methods of a SQL type

• Functions that in any other way help determine whether or where a row should appear in a result set

Oracle Database cannot require that you should explicitly declare functions in the preceding categories as DETERMINISTIC without breaking existing applications, but the use of the keyword might be a wise choice of style within your application.

Keep the following points in mind when you create DETERMINISTIC functions:

• The database cannot recognize if the behavior of the function is indeed deterministic. If the DETERMINISTIC keyword is applied to a function whose behavior is not truly deterministic, then the result of queries involving that function is unpredictable.

• If you change the semantics of a DETERMINISTIC function and recompile it, then existing function-based indexes and materialized views report results for the prior version of the function. Thus, if you change the semantics of a function, you must manually rebuild any dependent function-based indexes and materialized views.

Parallel Query and Parallel DML

Oracle Database's parallel execution feature divides the work of executing a SQL statement across multiple processes. Functions called from a SQL statement which is run in parallel may have a separate copy run in each of these processes, with each copy called for only the subset of rows that are handled by that process.

Each process has its own copy of package variables. When parallel execution begins, these are initialized based on the information in the package specification and body as if a new user is logging into the system; the values in package variables are not copied from the original login session. And changes made to package variables are not automatically propagated between the various sessions or back to the original session. Java STATIC class attributes are similarly initialized and modified independently in each process. Because a function can use package (or Java STATIC) variables to accumulate some value across the various rows it encounters, Oracle Database cannot assume that it is safe to parallelize the execution of all user-defined functions.

For query (SELECT) statements in Oracle Database versions prior to 8.1.5, the parallel query optimization looked to see if a function was noted as RNPS and WNPS in a PRAGMA RESTRICT_REFERENCES declaration; those functions that were marked as both RNPS and WNPS could be run in parallel. Functions defined with a CREATE FUNCTION statement had their code implicitly examined to determine if they were pure enough; parallelized execution might occur even though a pragma cannot be specified on these functions.

For DML statements in Oracle Database versions prior to 8.1.5, the parallelization optimization looked to see if a function was noted as having all four of RNDS, WNDS, RNPS and WNPS specified in a PRAGMA RESTRICT_REFERENCES declaration; those functions that were marked as neither reading nor writing to either the database or package variables could run in parallel. Again, those functions defined with a CREATE FUNCTION statement had their code implicitly examined to determine if they were actually pure enough; parallelized execution might occur even though a pragma cannot be specified on these functions.

Oracle Database versions 8.1.5 and later continue to parallelize those functions that earlier versions recognize as parallelizable. The PARALLEL_ENABLE keyword is the preferred way to mark your code as safe for parallel execution. This keyword is syntactically similar to DETERMINISTIC as described in "Declaring a Function"; it is placed after the return value type in a declaration of the function, as in:

CREATE FUNCTION F1 (P1 NUMBER) RETURN NUMBER PARALLEL_ENABLE IS
BEGIN
  RETURN P1 * 2;
END;

A PL/SQL function defined with CREATE FUNCTION may still be run in parallel without any explicit declaration that it is safe to do so, if the system can determine that it neither reads nor writes package variables nor calls any function that might do so. A Java method or C function is never seen by the system as safe to run in parallel, unless the programmer explicitly indicates PARALLEL_ENABLE on the "call specification", or provides a PRAGMA RESTRICT_REFERENCES indicating that the function is sufficiently pure.

An additional runtime restriction is imposed on functions run in parallel as part of a parallelized DML statement. Such a function is not permitted to in turn execute a DML statement; it is subject to the same restrictions that are enforced on functions that are run inside a query (SELECT) statement.

PRAGMA RESTRICT_REFERENCES – for Backward Compatibility

In Oracle Database versions prior to 8.1.5 (Oracle8i), programmers used the pragma RESTRICT_REFERENCES to assert the purity level of a subprogram. In subsequent versions, use the hints parallel-enable and deterministic, instead, to communicate subprogram purity to Oracle Database.

You can remove RESTRICT_REFERENCES from your code. However, this pragma remains available for backward compatibility in situations where one of the following is true:

• It is impossible or impractical to edit existing code to remove RESTRICT_REFERENCES completely. If you do not remove it from a subprogram S1 that depends on another subprogram S2, then RESTRICT_REFERENCES might also be needed in S2, so that S1 will compile.

• Replacing RESTRICT_REFERENCES in existing code with hints parallel-enable and deterministic would negatively affect the behavior of new, dependent code. Use RESTRICT_REFERENCES to preserve the behavior of the existing code.

An existing PL/SQL application can thus continue using the pragma even on new functionality, to ease integration with the existing code. Do not use the pragma in a wholly new application.

If you use the pragma RESTRICT_REFERENCES, place it in a package specification, not in a package body. It must follow the declaration of a subprogram (function or procedure), but it need not follow immediately. Only one pragma can reference a given subprogram declaration.

To code the pragma RESTRICT_REFERENCES, use the following syntax:

PRAGMA RESTRICT_REFERENCES (
    Function_name, WNDS [, WNPS] [, RNDS] [, RNPS] [, TRUST] );

Where:

You can pass the arguments in any order. If any SQL statement inside the subprogram body violates a rule, then you get an error when the statement is parsed.

In the following example, the function compound neither reads nor writes database or package state; therefore, you can assert the maximum purity level. Always assert the highest purity level that a subprogram allows. That way, the PL/SQL compiler never rejects the subprogram unnecessarily.

CREATE TABLE Accts (
 Yrs      NUMBER,
 Amt      NUMBER,
 Acctno   NUMBER,
 Rte      NUMBER);

CREATE PACKAGE Finance AS  -- package specification
   FUNCTION Compound
         (Years  IN NUMBER,
          Amount IN NUMBER,
          Rate   IN NUMBER) RETURN NUMBER;
   PRAGMA RESTRICT_REFERENCES (Compound, WNDS, WNPS, RNDS, RNPS);
END Finance;

CREATE PACKAGE BODY Finance AS  --package body
   FUNCTION Compound
         (Years  IN NUMBER,
          Amount IN NUMBER,
          Rate   IN NUMBER) RETURN NUMBER IS
   BEGIN
      RETURN Amount * POWER((Rate / 100) + 1, Years);
   END Compound;
                   -- no pragma in package body
END Finance;

Later, you might call compound from a PL/SQL block, as follows:

DECLARE
   Interest NUMBER;
   Acct_id NUMBER;
BEGIN
   SELECT Finance.Compound(Yrs, Amt, Rte)  -- function call
   INTO   Interest
   FROM   Accounts
   WHERE  Acctno = Acct_id;

CREATE OR REPLACE PACKAGE P1 IS
   FUNCTION F1 (P1 NUMBER) RETURN NUMBER IS
      LANGUAGE JAVA NAME 'CLASS1.METHODNAME(int) return int';
      PRAGMA RESTRICT_REFERENCES(F1,WNDS,TRUST);
   FUNCTION F2 (P1 NUMBER) RETURN NUMBER;

   PRAGMA RESTRICT_REFERENCES(F2,WNDS);
END;

CREATE OR REPLACE PACKAGE BODY P1 IS
   FUNCTION F2 (P1 NUMBER) RETURN NUMBER IS
   BEGIN
      RETURN F1(P1);
   END;
END;

CREATE OR REPLACE PACKAGE P1a IS
   FUNCTION F1 (P1 NUMBER) RETURN NUMBER IS
      LANGUAGE JAVA NAME 'CLASS1.METHODNAME(int) return int';
   FUNCTION F2 (P1 NUMBER) RETURN NUMBER;
   PRAGMA RESTRICT_REFERENCES(F2,WNDS,TRUST);
END;

CREATE OR REPLACE PACKAGE BODY P1a IS
   FUNCTION F2 (P1 NUMBER) RETURN NUMBER IS
   BEGIN
      RETURN F1(P1);
   END;
END;


INSERT INTO my_table values(3, 'SCOTT');

UPDATE my_table SET id=777 WHERE name='SCOTT';

CREATE PACKAGE Tests AS
    FUNCTION Valid (x NUMBER) RETURN CHAR;
    FUNCTION Valid (x DATE) RETURN CHAR;
    PRAGMA RESTRICT_REFERENCES (valid, WNDS);
 END;

Package States

The state of a nonreusable package (one not marked SERIALLY_REUSABLE) persists for the lifetime of a session. A package state includes global variables, cursors, and so on.

The state of a serially reusable package persists only for the lifetime of a call to the server. On a subsequent call to the server, if a reference is made to the serially reusable package, then Oracle Database creates a new instantiation of the serially reusable package and initializes all the global variables to NULL or to the default values provided. Any changes made to the serially reusable package state in the previous calls to the server are not visible.

Why Serially Reusable Packages?

Because the state of a non-reusable package persists for the lifetime of the session, this locks up UGA memory for the whole session. In applications, such as Oracle Office, a log-on session can typically exist for days together. Applications often need to use certain packages only for certain localized periods in the session and would ideally like to de-instantiate the package state in the middle of the session, after they are done using the package.

With SERIALLY_REUSABLE packages, application developers have a way of modelling their applications to manage their memory better for scalability. Package state that they care about only for the duration of a call to the server should be captured in SERIALLY_REUSABLE packages.

Syntax of Serially Reusable Packages

A package can be marked serially reusable by a pragma. The syntax of the pragma is:

PRAGMA SERIALLY_REUSABLE;


A package specification can be marked serially reusable, whether or not it has a corresponding package body. If the package has a body, then the body must have the serially reusable pragma, if its corresponding specification has the pragma; it cannot have the serially reusable pragma unless the specification also has the pragma.

Semantics of Serially Reusable Packages

A package that is marked SERIALLY_REUSABLE has the following properties:

• Its package variables are meant for use only within the work boundaries, which correspond to calls to the server (either OCI call boundaries or PL/SQL RPC calls to the server).




  Note: If the application programmer makes a mistake and depends on a package variable that is set in a previous unit of work, then the application program can fail. PL/SQL cannot check for such cases.




• A pool of package instantiations is kept, and whenever a "unit of work" needs this package, one of the instantiations is "reused", as follows:

  • The package variables are reinitialized (for example, if the package variables have default values, then those values are reinitialized).

  • The initialization code in the package body is run again.

• At the "end work" boundary, cleanup is done.

  • If any cursors were left open, then they are silently closed.

  • Some non-reusable secondary memory is freed (such as memory for collection variables or long VARCHAR2s).

  • This package instantiation is returned back to the pool of reusable instantiations kept for this package.

• Serially reusable packages cannot be accessed from database triggers or other PL/SQL subprograms that are called from SQL statements. If you try, then Oracle Database generates an error.

Examples of Serially Reusable Packages

This section presents a few examples of serially reusable packages.

CONNECT Scott/Tiger

CREATE OR REPLACE PACKAGE Sr_pkg IS
  PRAGMA SERIALLY_REUSABLE;
  N NUMBER := 5;                -- default initialization
END Sr_pkg;

CONNECT Scott/Tiger

# first CALL to server
BEGIN
   Sr_pkg.N := 10;
END;

# second CALL to server
BEGIN
   DBMS_OUTPUT.PUT_LINE(Sr_pkg.N);
END;

5

CONNECT Scott/Tiger

DROP PACKAGE Sr_pkg;
CREATE OR REPLACE PACKAGE Sr_pkg IS
   PRAGMA SERIALLY_REUSABLE;
   TYPE Str_table_type IS TABLE OF VARCHAR2(200) INDEX BY BINARY_INTEGER;
   Num     NUMBER        := 10;
   Str     VARCHAR2(200) := 'default-init-str';
   Str_tab STR_TABLE_TYPE;

    PROCEDURE Print_pkg;
    PROCEDURE Init_and_print_pkg(N NUMBER, V VARCHAR2);
END Sr_pkg;
CREATE OR REPLACE PACKAGE BODY Sr_pkg IS
   -- the body is required to have the pragma because the
  -- specification of this package has the pragma
  PRAGMA SERIALLY_REUSABLE;
   PROCEDURE Print_pkg IS
   BEGIN
      DBMS_OUTPUT.PUT_LINE('num: ' || Sr_pkg.Num);
      DBMS_OUTPUT.PUT_LINE('str: ' || Sr_pkg.Str);
      DBMS_OUTPUT.PUT_LINE('number of table elems: ' || Sr_pkg.Str_tab.Count);
      FOR i IN 1..Sr_pkg.Str_tab.Count LOOP
         DBMS_OUTPUT.PUT_LINE(Sr_pkg.Str_tab(i));
      END LOOP;
   END;
   PROCEDURE Init_and_print_pkg(N NUMBER, V VARCHAR2) IS
   BEGIN
   -- init the package globals
      Sr_pkg.Num := N;
      Sr_pkg.Str := V;
      FOR i IN 1..n LOOP
         Sr_pkg.Str_tab(i) := V || ' ' || i;
   END LOOP;
   -- print the package
   Print_pkg;
   END;
 END Sr_pkg;

SET SERVEROUTPUT ON;

Rem SR package access in a CALL:

BEGIN
   -- initialize and print the package
   DBMS_OUTPUT.PUT_LINE('Initing and printing pkg state..');
   Sr_pkg.Init_and_print_pkg(4, 'abracadabra');
   -- print it in the same call to the server.
   -- we should see the initialized values.
   DBMS_OUTPUT.PUT_LINE('Printing package state in the same CALL...');
   Sr_pkg.Print_pkg;
END;

Initing and printing pkg state..
num: 4
str: abracadabra
number of table elems: 4
abracadabra 1
abracadabra 2
abracadabra 3
abracadabra 4
Printing package state in the same CALL...
num: 4
str: abracadabra
number of table elems: 4
abracadabra 1
abracadabra 2
abracadabra 3
abracadabra 4

REM SR package access in subsequent CALL:
BEGIN
   -- print the package in the next call to the server.
   -- We should that the package state is reset to the initial (default) values.
   DBMS_OUTPUT.PUT_LINE('Printing package state in the next CALL...');
   Sr_pkg.Print_pkg;
END;
Statement processed.
Printing package state in the next CALL...
num: 10
str: default-init-str
number of table elems: 0

REM  For serially reusable pkg: At the end work boundaries
REM  (which is currently the OCI call boundary) all open
REM  cursors will be closed.
REM
REM  Because the cursor is closed - every time we fetch we
REM  will start at the first row again.

CONNECT Scott/Tiger
DROP PACKAGE  Sr_pkg;
DROP TABLE People;
CREATE TABLE People (Name VARCHAR2(20));
INSERT INTO  People  VALUES ('ET');
INSERT INTO  People  VALUES ('RAMBO');
CREATE OR REPLACE PACKAGE Sr_pkg IS
   PRAGMA SERIALLY_REUSABLE;
   CURSOR C IS SELECT Name FROM People;
END Sr_pkg;
SQL> SET SERVEROUTPUT ON;
SQL>
CREATE OR REPLACE PROCEDURE Fetch_from_cursor IS
Name VARCHAR2(200);
BEGIN
   IF (Sr_pkg.C%ISOPEN) THEN
      DBMS_OUTPUT.PUT_LINE('cursor is already open.');
   ELSE
      DBMS_OUTPUT.PUT_LINE('cursor is closed; opening now.');
      OPEN Sr_pkg.C;
   END IF;
   -- fetching from cursor.
   FETCH sr_pkg.C INTO name;
   DBMS_OUTPUT.PUT_LINE('fetched: ' || Name);
   FETCH Sr_pkg.C INTO name;
   DBMS_OUTPUT.PUT_LINE('fetched: ' || Name);
   -- Oops forgot to close the cursor (Sr_pkg.C).
   -- But, because it is a Serially Reusable pkg's cursor,
   -- it will be closed at the end of this CALL to the server.
END;
EXECUTE fetch_from_cursor;
cursor is closed; opening now.
fetched: ET
fetched: RAMBO
